Proportional valve – Control panel: For FCC gas injection technology

FCC 5 control panel
FCC 5 control panel
Control module with proportional valve
Control module with proportional valve

The control panel for the FCC gas injection technology supports precision gas injection at high and medium pressure based on pressure and time variables. Up to four proportional valves can be controlled independently of one another (up to a pressure of 400 bar) with the integrated PLC.

All the information you need at your fingertips!

Features

  • Large 10.4" colour touch screen with intuitive menu guidance
  • 1 to 4 proportional valves
  • Number of pressure / time profiles with ramp function: 7, independent for each channel
  • Number of programs: 99
  • Number of parts produced
  • Access protection: activation via password
  • Quality monitoring; process values (actual / setpoint comparison) as well as graphics-based display with alarms selected by user
  • Program and quality data saved on the internal CF card
  • Maintenance and alarm functions
Scope of delivery
Scope of delivery

Scope of delivery, basic equipment

  • FCC5 control panel with 1, 2 or 4 proportional valves
  • Operating instructions complete with spare parts list, CE declaration of conformity

For more detailed information, see the technical data sheets and quotations.

Technical data for the control panel
Display: 10.4" colour touch screen
Control: PLC: programmable logic controller
Display of pressure values: Real-time display of numerical values and characteristic curves
Data storage: On internal CF card, external via USB (program data and process data)
Interface: Ethernet connection for e.g.: remote diagnostics via Internet
Cleaning cycle: Manual or automatic
Power supply: 230 V / 50 Hz
Dimensions (L × W × H): 460 × 450 × 1300 mm
Weight: 62 kg (2 valves)
Technical data for the control module
Proportional valves: 1 to 2 per module; max. 2 modules
Type: High-pressure proportional valve
Max. input pressure: 400 bar
Precision: ± 1%
Pressure range: 5 to 400 bar
Control pressure range: 5 to 400 bar
Power supply: 24 V, 2.5 A min. per channel
Filter: 25 µm
Dimensions: 200 × 200 × 200 mm
Approx. weight: 12 kg (1 module)
